Insulation
Ultra Vision
Low solar heat gain coefficient will keep your home more comfortable
provides warm and natural appearance for your home and, building. This film offers a unique combination of low reflectivity, beauty, and high performance. It has dual reflective technology, providing daytime privacy while allowing easier viewing outside at night.Features and Benefits Protects from The Sun's Damaging Ultraviolet Rays
Reduces Glare by up to 83%
Protects your Daytime Privacy
Rejects up to 77% of The Total Solar Energy
Lower Interior and Exterior Reflectivity (The View of the Outside is Unaltered)
| Ultra Vision 25 (6mm Single clear) | |||||||||
|---|---|---|---|---|---|---|---|---|---|
| Visible Light Transmittance(%) | Visible Light Reflection(%) | Glare reduction | |||||||
| 25(%) | inner 24(%) |
outer 26(%) |
72(%) | ||||||
| Shading coefficient | Total Solar Energy Rejection(%) | U-Value | |||||||
| 0.34 | 66(%) | 0.92 | |||||||
| Ultra Vision 15 (6mm Single clear) | |||||||||
| Visible Light Transmittance(%) | Visible Light Reflection(%) | Glare reduction | |||||||
| 15(%) | 내부 13(%) |
외부 36(%) |
83(%) | ||||||
| Shading coefficient | Total Solar Energy Rejection(%) | U-Value | |||||||
| 0.29 | 66(%) | 0.92 | |||||||
| Visible Light Transmittance(%) | Visible Light Reflection(%) | Glare reduction | Shading coefficient | Total Solar Energy Rejection(%) | U-Value | ||
|---|---|---|---|---|---|---|---|
| inner | outer | ||||||
| Ultra Vision 25 (6mm Single clear) | 25(%) | 24(%) | 26(%) | 72(%) | 0.34 | 66(%) | 0.92 |
| Ultra Vision 15 (6mm Single clear) | 15(%) | 13(%) | 36(%) | 83(%) | 0.29 | 66(%) | 0.92 |
Stainless steel
A Smart Choice For Commercial & Residential Properties
RE Series improves the look and function of just about any buildings. It has high solar control performance and durability. The RE metal, laminating adhesives and scratch-resistant coating used in this film provides high performance, durability and longevity.Features and Benefits All-Purpose with Extreme Heat Rejection
Improves Exterior Appearance
Excellent Durability
Blocks 99% of UV Rays, Prevents from Fading
| RE 20 SS | |||||||||
|---|---|---|---|---|---|---|---|---|---|
| Visible Light Transmittance(%) | Visible Light Reflection(%) | ||||||||
| 21 | 30 | ||||||||
| Visible Light Reflectance(E) | UV Rejected(%) | Total Solar Energy Rejection(%) | |||||||
| 25 | 99 | 68 | |||||||
| RE 35 SS | |||||||||
| Visible Light Transmittance(%) | Visible Light Reflection(%) | ||||||||
| 33 | 16 | ||||||||
| Visible Light Reflectance(E) | UV Rejected(%) | Total Solar Energy Rejection(%) | |||||||
| 16 | 99 | 52 | |||||||
| Visible Light Transmittance(%) | Visible Light Reflection(%) | Visible Light Reflectance(E) | UV Rejected(%) | Total Solar Energy Rejection(%) | |
|---|---|---|---|---|---|
| RE 20 SS | 21 | 30 | 25 | 99 | 68 |
| RE 35 SS | 33 | 16 | 16 | 99 | 52 |
Silver
Silver series is an architectural film with the highest heat rejection and reflection. It creates a colorful appearance with a subtle silver color. It can be protected from privacy violations with a high reflection and Shading Coefficient and can enjoy a more comfortable life.
Features and Benefits All-purpose with high efficiency
Superior privacy protection
Color suitable for building appearance
Blocks 99% UV rays prevents interior discoloration
Features and Benefits All-purpose with high efficiency
Superior privacy protection
Color suitable for building appearance
Blocks 99% UV rays prevents interior discoloration
| Silver 20 (6mm Single clear) | |||||||||
|---|---|---|---|---|---|---|---|---|---|
| Visible Light Transmittance(%) | Visible Light Reflection(%) | UV Rejected(%) | Total Solar Energy Rejection(%) | ||||||
| 16 | 56 | <2 | 77 | ||||||
| Silver 35 (6mm Single clear) | |||||||||
| Visible Light Transmittance(%) | Visible Light Reflection(%) | UV Rejected(%) | Total Solar Energy Rejection(%) | ||||||
| 33 | 36 | <2 | 64 | ||||||
| Silver 50 (6mm Single clear) | |||||||||
| Visible Light Transmittance(%) | Visible Light Reflection(%) | UV Rejected(%) | Total Solar Energy Rejection(%) | ||||||
| 47 | 29 | <2 | 56 | ||||||
| Visible Light Transmittance(%) | Visible Light Reflection(%) | UV Rejected(%) | Total Solar Energy Rejection(%) | |
|---|---|---|---|---|
| Silver 20 (6mm Single clear) | 16 | 56 | <2 | 77 |
| Silver 35 (6mm Single clear) | 33 | 36 | <2 | 64 |
| Silver 50 (6mm Single clear) | 47 | 29 | <2 | 56 |
Aluminum
Aluminum series is architectural film with the highest heat rejection and reflection. It can be protected from privacy violations with a high reflection and Shading Coefficient and can enjoy a more comfortable life.
Features and Benefits Features and Benefits
All-purpose with high efficiency
Superior privacy protection
Blocks 99% UV rays prevents interior discoloration
Features and Benefits Features and Benefits
All-purpose with high efficiency
Superior privacy protection
Blocks 99% UV rays prevents interior discoloration
| GREY SILVER 20 (6mm Single clear) | |||||||||
|---|---|---|---|---|---|---|---|---|---|
| Visible Light Transmittance(%) | Visible Light Reflection(%) | UV Rejected(%) | Total Solar Energy Rejection(%) | ||||||
| 13 | 31 | <2 | 68 | ||||||
| GREEN SILVER 20 (6mm Single clear) | |||||||||
| Visible Light Transmittance(%) | Visible Light Reflection(%) | UV Rejected(%) | Total Solar Energy Rejection(%) | ||||||
| 12 | 65 | <2 | 77 | ||||||
| GOLD SILVER 20 (3mm Single clear) | |||||||||
| Visible Light Transmittance(%) | Visible Light Reflection(%) | UV Rejected(%) | Total Solar Energy Rejection(%) | ||||||
| 15 | 59 | <2 | 77 | ||||||
| BLUE SILVER 20 (3mm Single clear) | |||||||||
| Visible Light Transmittance(%) | Visible Light Reflection(%) | UV Rejected(%) | Total Solar Energy Rejection(%) | ||||||
| 12 | 57 | <2 | 77 | ||||||
| BRONZE SILVER 20 (3mm Single clear) | |||||||||
| Visible Light Transmittance(%) | Visible Light Reflection(%) | UV Rejected(%) | Total Solar Energy Rejection(%) | ||||||
| 16 | 37 | <2 | 68 | ||||||
| Visible Light Transmittance(%) | Visible Light Reflection(%) | UV Rejected(%) | Total Solar Energy Rejection(%) | |
|---|---|---|---|---|
| GREY SILVER 20 (6mm Single clear) | 13 | 31 | <2 | 68 |
| GREEN SILVER 20 (6mm Single clear) | 12 | 65 | <2 | 77 |
| GOLD SILVER 20 (3mm Single clear) | 15 | 59 | <2 | 77 |
| BLUE SILVER 20 (3mm Single clear) | 12 | 57 | <2 | 77 |
| BRONZE SILVER 20 (3mm Single clear) | 16 | 37 | <2 | 68 |
Solar Bronze
The V-Tech Solar Bronze series makes the windows glow with their warm copper color combinations. It protects privacy while blocking the sun's hot heat, while maximizing the naturalness of natural light, making the living space more sophisticated.
Features and Benefits copper saturation
High heat blocking rate and privacy protection effect
natural indoor lighting
Features and Benefits copper saturation
High heat blocking rate and privacy protection effect
natural indoor lighting
| SOLAR BRONZE 20 (6mm Single clear) | |||||||||
|---|---|---|---|---|---|---|---|---|---|
| Visible Light Transmittance(%) | Visible Light Reflection(%) | UV Rejected(%) | Total Solar Energy Rejection(%) | ||||||
| 21 | 36 | <2 | 77 | ||||||
| SOLAR BRONZE 35 (6mm Single clear) | |||||||||
| Visible Light Transmittance(%) | Visible Light Reflection(%) | UV Rejected(%) | Total Solar Energy Rejection(%) | ||||||
| 34 | 27 | <2 | 70 | ||||||
| SOLAR BRONZE 50 (3mm Single clear) | |||||||||
| Visible Light Transmittance(%) | Visible Light Reflection(%) | UV Rejected(%) | Total Solar Energy Rejection(%) | ||||||
| 44 | 21 | <2 | 62 | ||||||
| LE 20 BRONZE | |||||||||
| Visible Light Transmittance(%) | Visible Light Reflection(%) | UV Rejected(%) | Total Solar Energy Rejection(%) | ||||||
| 25 | 34 | <2 | 78 | ||||||
| LE 35 BRONZE | |||||||||
| Visible Light Transmittance(%) | Visible Light Reflection(%) | UV Rejected(%) | Total Solar Energy Rejection(%) | ||||||
| 37 | 22 | <2 | 61 | ||||||
| Visible Light Transmittance(%) | Visible Light Reflection(%) | UV Rejected(%) | Total Solar Energy Rejection(%) | |
|---|---|---|---|---|
| SOLAR BRONZE 20 (6mm Single clear) | 21 | 36 | <2 | 77 |
| SOLAR BRONZE 35 (6mm Single clear) | 34 | 27 | <2 | 70 |
| SOLAR BRONZE 50 (3mm Single clear) | 44 | 21 | <2 | 62 |
| LE 20 BRONZE | 25 | 34 | <2 | 78 |
| LE 35 BRONZE | 37 | 22 | <2 | 61 |
Crystal Sputter
Crystal Sputter film provides a clear, dazzling view with transparency. It offers excellent solar protection, and is reflective outside with a neutral inside look.
Features and Benefits Superior Solar Control
Clear view without glare
99% UV protection
Features and Benefits Superior Solar Control
Clear view without glare
99% UV protection
| Crystal Sputter (6mm Single clear) | |||||||||
|---|---|---|---|---|---|---|---|---|---|
| Visible Light Transmittance(%) | Visible Light Reflection(%) | UV Rejected(%) | Total Solar Energy Rejection(%) | ||||||
| 70 | 20 | <1 | 45 | ||||||
| Visible Light Transmittance(%) | Visible Light Reflection(%) | UV Rejected(%) | Total Solar Energy Rejection(%) | |
|---|---|---|---|---|
| Crystal Sputter (6mm Single clear) | 70 | 20 | <1 | 45 |
